Work Smarter. Tie Faster. Stay Upright.

The RB401T-E Stand-Up Rebar Tying Tool is designed to make high-volume concrete and reinforcing steel work faster, more efficient, and more comfortable. Capable of tying rebar grids from 10mm x 10mm up to 20mm x 20mm using 1.0mm wire, this innovative stand-up rebar tying tool allows operators to work from an upright position, helping reduce bending, back strain and fatigue on demanding job sites.

Featuring triggerless operation, the RB401T-E automatically activates when the tying arm makes contact with the rebar, delivering fast and consistent ties in approximately 0.7 seconds.

The tool incorporates a TwinTier Wire Bending Mechanism that produces a compact, low-profile tie, helping reduce the amount of concrete cover required while maintaining an efficient and secure tie.

With its ergonomic long-frame design and slim tying arm, the RB401T-E is particularly well suited to large concrete slabs, foundations, roads, bridges, tilt-up panels and commercial construction projects.

Key Benefits

• Stand-up operation helps reduce bending, back strain and operator fatigue.

• Fast 0.7-second tie speed helps improve productivity on high-volume projects.

• Triggerless technology automatically activates on contact for quick, consistent tying.

• Compact tie profile can help minimise concrete requirements for cover.

• Slim tying arm provides improved access in tight spaces and difficult positions.

• Suitable for rebar grids up to 20mm x 20mm.

• Designed for use with compatible TWINTIER wire and batteries.

Applications

The RB401T-E is ideal for a wide range of reinforcing and concrete construction applications, including:

• Road and bridge construction

• Building foundations

• Concrete slabs

• Tilt-up panels

• Commercial concrete projects

• Reinforcing steel and rebar installation

• Large-scale concrete construction

Features

Stand-Up Operation – Reduce Back Strain

The ergonomic long-frame design allows operators to tie rebar while standing upright, significantly reducing the need for repetitive bending. This can help improve operator comfort and productivity during long days on the job.

Triggerless Technology – Fast, Effortless Tying

The RB401T-E automatically activates when the tying arm contacts the rebar. With no trigger to pull, operators can quickly move from one tie to the next, making the tool ideal for high-volume reinforcing work.

Compact Tie Height – Efficient Concrete Coverage

The innovative TwinTier Wire Bending Mechanism creates a low-profile tie that can help reduce the amount of concrete required for coverage. This design provides an efficient solution for concrete reinforcement applications where tie height is important.

Slim Tying Arm – Access Tight Areas

The narrow tying arm is designed to access tight corners and challenging positions, including angled applications of approximately 45 degrees. This provides greater flexibility when working across complex rebar layouts.

Specifications

SpecificationDetailsWeight4.6 kgDimensions322mm (H) x 408mm (W) x 1100mm (L)Minimum Ties Per Coil155Maximum Ties Per Coil260Applicable WireTW1061T / 19Ga, TW1061T-PC / 19Ga, TW1061T-EG / 19Ga, TW1061T-S / 19GaApplicable Rebar Size10mm x 10mm up to 20mm x 20mmTies Per ChargeUp to 4,600Tie SpeedApproximately 0.7 secondsTie Wraps1 wrap with double wireBattery Charge Time80% in approximately 60 minutes; 100% in approximately 80 minutesBatteryJPL91440A x 2ChargerJC925A x 1

Compatible Wire

The RB401T-E is compatible with the following 19-gauge wire products:

• TW1061T

• TW1061T-PC

• TW1061T-EG

• TW1061T-S

Why Choose the RB401T-E?

When you're tying hundreds or thousands of rebar intersections on a large concrete project, operator comfort and tying speed can have a major impact on productivity.

The RB401T-E combines stand-up ergonomics, automatic triggerless operation and rapid tying performance in one purpose-built rebar tying solution. It's an ideal choice for contractors looking to reduce repetitive bending and improve efficiency across large-scale concrete and reinforcing projects.

Suitable for professional concrete contractors, reinforcing steel installers, civil construction crews and commercial building projects.
