Heavy-Duty Digital Rebar Bender & Cutter for High-Volume Production

The RAPIDTOOL PRBC-28X Premium Rebar Bender + Cutter is a heavy-duty, production-grade machine designed for fast, accurate and repeatable rebar processing. Combining rebar bending and cutting in one powerful machine, the PRBC-28X is an ideal solution for precast concrete facilities, rebar fabrication workshops, construction companies and high-volume steel processing environments.

With a 6–28mm bending capacity and 6–24mm cutting capacity, the PRBC-28X provides the versatility required to process a wide range of reinforcement bar sizes. Its advanced digital control system allows operators to preset multiple bend angles and monitor production with the integrated bend counter.

Designed and manufactured in Europe through the RAPIDTOOL – ICARO partnership, the PRBC-28X is engineered for demanding Australian and New Zealand working environments and is supported locally by RAPIDTOOL with spare parts and professional servicing.

Key Features

• 6–28mm Rebar Bending Capacity – Processes a wide range of reinforcement bar sizes.

• 6–24mm Rebar Cutting Capacity – Cut rebar efficiently without requiring a separate machine.

• Combined Bending & Cutting – Two essential rebar processing functions in one heavy-duty machine.

• Advanced Digital Controls – Preset multiple bend angles for fast and repeatable production.

• Integrated Bend Counter – Helps operators monitor production and maintain consistency.

• Multi-Bar Processing – Bend or cut multiple bars where capacity allows to improve productivity.

• Bidirectional Bend Table – Forward and reverse rotation provides greater flexibility when forming complex bends.

• Heavy-Duty Three-Phase Motor – Designed for continuous, high-output operation.

• Foot Pedal Control – Provides convenient and efficient operator control.

• Interlocked Safety Guards & Door Sensors – Designed with operator safety in mind.

• Industrial-Strength Frame – Built for demanding workshop and production environments.

• Multiple Bend Pins & Bushings – Supplied with a range of diameters, with custom sizes available.

• Optional Forming Tools – Ligature/stirrup, spiral and rebar ring forming accessories are available.

• European Engineering – Manufactured for demanding professional applications.

• Australian Local Support – RAPIDTOOL provides local parts, servicing and priority support.

Advanced Digital Rebar Bending Control

The PRBC-28X features an integrated digital control system designed to simplify repetitive bending operations. Operators can preset close to 400 bend angles, helping improve consistency across production runs.

The built-in digital bend counter provides an easy way to monitor completed bends, making the PRBC-28X well suited to high-volume rebar fabrication and production environments.

Powerful Rebar Bending & Cutting Performance

The PRBC-28X is designed to process both single and multiple bars, helping reduce production time and improve workflow efficiency.

Bending Capacity

• 6–28mm rebar

• 28mm – 1 bar

• 22mm – 2 bars

• 18mm – 3 bars

Cutting Capacity

• 6–24mm rebar

• 24mm – 1 bar

• 18mm – 2 bars

• 12mm – 3 bars

This combination of bending and cutting capability makes the PRBC-28X a versatile choice for rebar fabrication, precast production and construction-related steel processing.

Bidirectional Bending for Greater Flexibility

The reversible bending table allows forward and reverse rotation, giving operators greater flexibility when producing complex shapes and bends.

Combined with multiple bend pin and bushing diameters, the PRBC-28X can be configured for a broad range of rebar fabrication requirements.

Optional Ligature, Stirrup, Spiral & Rebar Ring Tools

Optional forming accessories expand the machine's capabilities for specialist rebar production.

Available accessories include:

• Ligature forming tools

• Stirrup forming tools

• Spiral forming tools

• Rebar ring forming tools

These options make the PRBC-28X suitable for businesses producing a variety of reinforcement shapes and components.

Heavy-Duty Three-Phase Construction

Built for demanding production environments, the PRBC-28X uses a robust three-phase hybrid drive system and heavy-duty industrial construction.

The machine is designed for continuous operation under load, making it suitable for professional rebar processing facilities where reliability, repeatability and productivity are essential.

Safety-Focused Design

Operator safety is an important part of the PRBC-28X design. The machine incorporates interlocked safety guards, sensor-activated doors and foot pedal control to help provide a safer working environment.

All installation and electrical work must be completed by a licensed electrician.

European Engineering. Australian Support.

The PRBC-28X is part of the RAPIDTOOL – ICARO Premium Rebar Machinery range, combining European manufacturing with local Australian support.

RAPIDTOOL is the exclusive Australian, New Zealand and Pacific Islands dealer and authorised service agent for ICARO rebar machinery.

Customers benefit from local access to:

• Spare parts

• Professional servicing

• Technical support

• Priority service

• Local product support

Specifications

SpecificationPRBC-28XBrandRAPIDTOOL – ICAROModelPRBC-28XDescriptionRAPIDTOOL PREMIUM 400–415V Heavy Duty 6–28mm Rebar Bender + 6–24mm Rebar CutterPoles4Rated Voltage400–415V 3~Rated Frequency50HzRated Power2.2kWRated Current5.4ANumber of Phases3Full Load Motor Speed1420 RPMAverage Bend Cycle Speed10 RPMRated Bending Diameter Range6–28mm (650MPa)Rated Cutting Diameter Range6–24mm (650MPa)Maximum Bending Capacity28mm – 1 Bar / 22mm – 2 Bars / 18mm – 3 BarsMaximum Cutting Capacity24mm – 1 Bar / 18mm – 2 Bars / 12mm – 3 BarsNet Weight320kgMachine Dimensions105cm x 75cm x 85cmIncluded AccessoriesSquaring Arm Set, Pins, Bushings, Foot Pedal & Safety GuardBend Pin/Bushing Diameters25 / 32 / 50 / 60 / 80 / 100mmCustom BushingsAvailableOptional AccessoriesStirrup/Ligature + Spiral/Rebar Ring Forming Tools

Features and specifications are approximate only. Refer to the product datasheet for full details.

Applications

The RAPIDTOOL PRBC-28X is suitable for a wide range of professional rebar processing applications, including:

• Precast concrete production

• Rebar fabrication workshops

• Rebar processing facilities

• Infrastructure projects

• Civil construction

• Commercial construction

• Residential construction

• Reinforcement steel preparation

• High-volume rebar production

Why Choose the PRBC-28X?

The RAPIDTOOL PRBC-28X Heavy Duty Rebar Bender + Cutter combines two essential rebar processing functions in a single production-grade machine.

With digital bend programming, an integrated bend counter, multi-bar processing, bidirectional bending and a heavy-duty three-phase drive system, it is designed to help professional operators achieve fast, consistent and repeatable results.

For businesses looking to increase production efficiency while reducing the need for separate bending and cutting equipment, the PRBC-28X offers a versatile solution backed by RAPIDTOOL's Australian parts, servicing and technical support.

Installation must be carried out by a licensed electrician.
